IM171-Wind Speed Sensor

Manufactured to WMO guidelines. This system consists of a Paperless Recorder and Wind Speed Sensor only.

Add to Quotation

Description

Wind Speed Transmitter

The system is manufactured in the UK in accordance with WMO guidelines. This system provides 10 and 2-minute averages, gust/maximum and minimum recordings.

The Paperless Recorder (PR) is a data acquisition unit with a 5.6″ TFT touch screen. Designed for Wind Speed only  The IM171-S is ideally suited for customers who require Wind speed data. The PR is supplied with PC software which offers multiple real-time and historical views, as well as numerous archiving strategies to ensure data is never lost.

Please specify your application, sensors required and if a calibration certificate with test results is required when requesting a quotation.

What are Wind Speed Transmitter

A wind speed transmitter is an instrument used to measure the speed of the wind. It converts the kinetic energy of the wind into an electrical signal, which can then be processed and displayed as wind speed in units such as meters per second (m/s) or kilometers per hour (km/h).





Additional information

Scale

Knots, Metres per Second, Miles per Hour

Certificate of Conformity

Yes, No

Product Specifications

Data Logger

Power 90-250VAC or 11-36VDC
Display 5.6″ TFT touch screen
Resolution 640×480 pixel resolution, 65K colour
Internal Memory,

RAM

External Memory

Ethernet

256 MB

256 MB

SDcard,USBx2

Modbus TCP/IP

Sample Rate

Maths Channels

100ms max

Yes

Protection

Operating Temp

IP65F, IP20R

0°C to 50° C

Brochure

IM171-S
